CEFX SD9043MAC

[Kevin Wilson-Smith]

Most effective at pulling loads over long stretches at moderate speeds.
Power: 4,300 hp
Max. speed: 65 mph (105 km/h)
Gear ratio: 83:16
Power source: EMD 16-710G3B-EC, Alternator AR20
Road Numbers: 100-139, Total Delivered: 40 in 1999-2000
Max. continuous tractive effort: 147,000 Lbs. @11.4mph
Wheel configuration: Twelve 42-inch (106.5 cm) diameter in C-C configuration (two sets of three driven axles)
Height: 15 ft. 5 in. (4.70 m)
Width: 10 ft. 3 in. (3.12 m)
Length: 73 ft. 2 in. (22.25 m)
Weight: 210 U.S. tons (190.5 metric tons)
